Kilo Volt Meter
50000.00 - 100000.00 INR/Set
Product Details:
- Product Type Kilo Volt Meter
- Material MS
- Measuring Voltage Range Up to 800kV and 250mA Volt (v)
- Operating Temperature 0-50 Deg. C Celsius (oC)
- Frequency (MHz) 50 Hz Hertz (HZ)
- Insulation Box Output through Banana Clips
- Protection System Over Load , Over current and earth fault protection
- Click to View more
X
Kilo Volt Meter Price And Quantity
- 50000.00 - 100000.00 INR/Set
- 01 Set
Kilo Volt Meter Product Specifications
- Over Load , Over current and earth fault protection
- RAL-7032
- Up to 800kV and 250mA Volt (v)
- Output through Banana Clips
- 50 Hz Hertz (HZ)
- Depends on current rating required by Customer Nanometer (nm)
- Depends on rating required by customer
- 12 Months from Manufacturing
- Kilo Volt Meter
- 0-50 Deg. C Celsius (oC)
- MS
- Depends on current rating required by Customer Kilograms (kg)
Kilo Volt Meter Trade Information
- Delhi
- 3 Set Per Year
- 8 Week
- Yes
- Contact us for information regarding our sample policy
- Bubble Wrap Packing Wooden packing with water proof or As per customer requirement.
- All India
- ISO 9001:2008 ISO : 14001 and OHSAS : 18000
Product Description
Kilo Volt Meter (kV) meters used to measure the kilo volt value of an Instrument Transformer, CT/PT etc. The unit is used for higher value calibration with a wide range from 1% to 110%. Kilo Voltmeters are highly accurate, portable voltage measurement systems traceable to NABL standards. The Kilo meter series consists of a high voltage divider assembly, a precision readout device and interconnection leads. The battery operation makes the system completely portable for field testing while the precision divider assembly and readout device makes it suitable for laboratory use.
Features :-
- Used to measure AC/DC voltage measurement / partial Discharge measurement from any High Voltage source such as AC HV test system, PT/CT power / distribution transformer.
- Available up to 800Kv.
- Variable Capacitance from 50pf to 1nf.
- Perform multiple measurements.
- DC measurement, AC peak, AC-RMS,True Value.
- Digital Read out.AC/DC Coupling.
- Battery or line power, Built in Self regulating battery charger.
- Light weight & portable divider.
Technical Specifications :-
| Kilo Volt Meter | |
| Parameters | Description |
| Maximum Capacity | Up to 800kV |
| Number of Sections | One for each 200kV or one for 100kV depends on capacity |
| Length of Section | 100kV - 0.75 meter 200kV - 1.25meter |
| Capacitance of the unit | Generally 200pF |
| Measured Parameter | Peak Voltage, RMS Voltage, DC Voltage and peak sq.root 2 |
| Frequency Response (AC) | AC 40 to 60HZ |
| AC 40 to 200HZ | |
| Frequency Response (DC) | Up to 1MHz |
| Least Count | 0.1kV |
| Enclosure | FRP |
