Variable Transformer
50000.00 - 100000.00 INR/Set
Product Details:
- Product Type Variable Autotransformer up to 2000A
- Material MS
- Measuring Voltage Range Up to 800kV and 250mA Volt (v)
- Operating Temperature 0-50 Deg. C Celsius (oC)
- Frequency (MHz) 50 Hz Hertz (HZ)
- Insulation Box Output through busbar on backlite
- Protection System Overload, Over current and earth fault protetion
- Click to View more
X
Variable Transformer Price And Quantity
- 01 Set
- 50000.00 - 100000.00 INR/Set
Variable Transformer Product Specifications
- MS
- Overload, Over current and earth fault protetion
- Up to 800kV and 250mA Volt (v)
- Variable Autotransformer up to 2000A
- Output through busbar on backlite
- 12 Months from Manufacturing
- RAL-7032
- Depends on current rating required by Customer
- Depends on current rating required by Customer Millimeter (mm)
- 0-50 Deg. C Celsius (oC)
- 50 Hz Hertz (HZ)
- Depends on current rating required by Customer Kilograms (kg)
Variable Transformer Trade Information
- Delhi
- 3 Set Per Year
- 8 Week
- Contact us for information regarding our sample policy
- Bubble wrap Packing Wooden packing with water proof or As per customer requirement.
- All India
- ISO 9001 : 2008 ISO : 14001 and OHSAS : 18000
Product Description
RE VARITX is the trade name of the continuously variable voltage Auto transformer manufactured by RE. It is an most economical effective device for step less and continuous voltage control of Single Phase and 3 phase AC voltages for numerous applications for the industrial and Laboratories usages for testing and calibration purposes. RE VARITX are used for operation at nominal voltage of 240V AC to give output Voltages between 0 to 270V at 50/60 Hz by a Booster Auto Transformer. Three such RE VARITX connected electrically in star and mechanically interlocked to move together are used for operation on 415 Volts, 3 phase AC supply to give output from voltage from 0 to 470 Volt at 50/60Hz. RE Manufactured VARITX is having good Regulation with Negligible waveform distortion. Varitx are robust, energy efficient, noiseless and easy to operate with excellent short time over load capabilities. RE manufacturers specialized Oil cooled or air cooled motorized/manually operated VARITX upto 800 Amps with supply voltage of 240 Volts to give output voltages from 0 to 350 Volts, 3 Phase VARITX up to 800Amps with input supply voltage of 415 Volt 3 Phase to give output Voltages from 0 to 600V.
Features
- Compact in Size.
- Rugged Construction.
- High Efficiency
- Neozero waveform distortion.
- Digitized operation and control and monitoring
- Easy to operate.
- Negligible maintenance trouble free operation.
Standard Accessories
Main Unit
Optional Accessories
All input and output cables
Technical Specifications :-
| Continuously Variable Auto Transformer | |
| Parameters | Description |
| Maximum Current Rating | Up to 2000A |
| Input Voltage | Single Phase and Three Phase depends on capacity |
| Output Voltage | Variable |
| Designed | For Continuous use |
| Types | Open Manual (Air Cooled) |
| Confirms to | IS : 985 |
| Operating Temperature | 0 Deg. To 50 Deg.C |
| Humidity | Upto 95%RH |
